Read from the text layer in 73 ms: 1,163 characters across 240 laid-out runs, tier 3a. Marks below are TEXT labels at their own positions, not a geometry sweep — on a tier-1 set text tag counts beat a visual sweep, and a mark read off a label arrives named rather than as a shape nobody can identify. No scale callout was found, so the scale is UNSET and nothing here has been measured. The reader declines to infer a scale rather than guess one. No schedule was found on this sheet, so the whole plan area was swept.
Names come from: no legend on this sheet, so NECA 100-2006 is what a name rests on. It is the baseline for what a symbol MEANS, never for matching shapes — proportions differ per firm. Confirming a name here is a correction, and corrections are what build the firm's file.
Scale is UNSET. Nothing on this sheet has been measured. The reader declined to infer a scale rather than guess one, so there is no raceway and no branch wire off this sheet — together the largest block of material on a job of this kind. Set it from the title block and measurement becomes available.
Put your name in to mark this sheet up. Looking needs no name.
zoom100%sheetcounts98 of 98 marks drawn
Page 4 of Copy of 2498 E set 2025-0530 Revision 1.pdf, recorded by the read.
Fetching page 4…
0 changes on this sheet, each saved as it was made · not saved as reviewed yet
The reader could not settle these3
Put your name in above to answer these.
43What is this symbol?
text label · 6.2 pt · mounting height
The reader thinks mounting height but is not sure. Hover to see where they are on the drawing.
