A-004 ADA, Egress and Fire Safety Floor Plan (3/16"=1'-0"). Font is glyph-shifted (+29); tags decoded from the text layer and confirmed on 190-dpi crops. EM2 = 13 tags (small boxed tag with two circles, mostly paired over egress arrows), EM3 = 4 (BOH), EM5 = 14 (circle symbol). No EM1 or EM4 tag drawn; strobe / pull station / smoke detector appear in the legend only. Page is rotated 90 deg; coordinates are in the displayed page space. EM5 marks are already_counted (E-300 /EMB count 18).
Names come from: no legend on this sheet, so NECA 100-2006 is what a name rests on. It is the baseline for what a symbol MEANS, never for matching shapes — proportions differ per firm. Confirming a name here is a correction, and corrections are what build the firm's file.
Scale is UNSET. Nothing on this sheet has been measured. The reader declined to infer a scale rather than guess one, so there is no raceway and no branch wire off this sheet — together the largest block of material on a job of this kind. Set it from the title block and measurement becomes available.
