Read from the text layer in 44 ms: 2,600 characters across 168 laid-out runs, tier 2. Marks below are TEXT labels at their own positions, not a geometry sweep — on a tier-1 set text tag counts beat a visual sweep, and a mark read off a label arrives named rather than as a shape nobody can identify. No scale callout was found, so the scale is UNSET and nothing here has been measured. The reader declines to infer a scale rather than guess one. No schedule was found on this sheet, so the whole plan area was swept.
Names come from: no legend on this sheet, so NECA 100-2006 is what a name rests on. It is the baseline for what a symbol MEANS, never for matching shapes — proportions differ per firm. Confirming a name here is a correction, and corrections are what build the firm's file.
Scale is UNSET. Nothing on this sheet has been measured. The reader declined to infer a scale rather than guess one, so there is no raceway and no branch wire off this sheet — together the largest block of material on a job of this kind. Set it from the title block and measurement becomes available.
No marks on this sheet. The full read placed nothing here; the only labels it had were from the quick preview (letters in the title block), and they are not findings.
