Specification sheet, lettering drawn as outlines (753 text characters against 36,750 drawing objects). The symbol scan found 20 groups, every one of them letter shapes of the specification text; all set aside. No plan, no scale, no devices and no homerun callouts on this sheet, so no line is counted off it; the specification clauses that change quantities on the plan sheets are listed in the sheet's coverage notes.
Names come from: this sheet's own legend. The title block types this sheet as the legend sheet.
Scale is UNSET. Nothing on this sheet has been measured. The reader declined to infer a scale rather than guess one, so there is no raceway and no branch wire off this sheet — together the largest block of material on a job of this kind. Set it from the title block and measurement becomes available.
