Read from the text layer in 70 ms: 14,810 characters across 633 laid-out runs, tier 1. Marks below are TEXT labels at their own positions, not a geometry sweep — on a tier-1 set text tag counts beat a visual sweep, and a mark read off a label arrives named rather than as a shape nobody can identify. No scale callout was found, so the scale is UNSET and nothing here has been measured. The reader declines to infer a scale rather than guess one. The schedule regions on this sheet (RELAY PANEL SCHEDULE FOR NUMBER OF RELAYS) are excluded by coordinate so their rows are not counted as plan content.
Names come from: no legend on this sheet, so NECA 100-2006 is what a name rests on. It is the baseline for what a symbol MEANS, never for matching shapes — proportions differ per firm. Confirming a name here is a correction, and corrections are what build the firm's file.
Scale is UNSET. Nothing on this sheet has been measured. The reader declined to infer a scale rather than guess one, so there is no raceway and no branch wire off this sheet — together the largest block of material on a job of this kind. Set it from the title block and measurement becomes available.
