Read from the text layer in 78 ms: 10,675 characters across 823 laid-out runs, tier 1. Marks below are TEXT labels at their own positions, not a geometry sweep — on a tier-1 set text tag counts beat a visual sweep, and a mark read off a label arrives named rather than as a shape nobody can identify. Scale read off the sheet as 1/4" = 1'-0" — 18 points per foot. The schedule regions on this sheet (LIGHTING CONTROL COMPONENTS SCHEDULE; LIGHTING FIXTURE SCHEDULE; LIGHTING CONTROL PANEL SCHEDULE: LCP) are excluded by coordinate so their rows are not counted as plan content.
Names come from: no legend on this sheet, so NECA 100-2006 is what a name rests on. It is the baseline for what a symbol MEANS, never for matching shapes — proportions differ per firm. Confirming a name here is a correction, and corrections are what build the firm's file.
Scale is 1/4" = 1'-0" — 18 points per foot. Read off the title block, so measurement off this sheet is available. A later correction flags any measurement taken under the old scale as stale rather than silently recomputing it.
The reader found 69 marks on this sheet. 67 stand now 3 struck. The reader’s own number is kept as it was written: it is what the accuracy history is scored against, and it does not move because somebody corrected the sheet.
