Read from the text layer in 131 ms: 3,571 characters across 262 laid-out runs, tier 3a. Marks below are TEXT labels at their own positions, not a geometry sweep — on a tier-1 set text tag counts beat a visual sweep, and a mark read off a label arrives named rather than as a shape nobody can identify. Scale read off the sheet as 3/8" = 1'-0" — 27 points per foot. No schedule was found on this sheet, so the whole plan area was swept.
Names come from: no legend on this sheet, so NECA 100-2006 is what a name rests on. It is the baseline for what a symbol MEANS, never for matching shapes — proportions differ per firm. Confirming a name here is a correction, and corrections are what build the firm's file.
Scale is 3/8" = 1'-0" — 27 points per foot. Read off the title block, so measurement off this sheet is available. A later correction flags any measurement taken under the old scale as stale rather than silently recomputing it.
No marks on this sheet. The full read placed nothing here; the only labels it had were from the quick preview (letters in the title block), and they are not findings.
