DS1 — STRUCTURAL FOUNDATION DETAILS

Other-trade sheet read for electrical scope only. Detail 15 MAIN SWITCHBOARD ATTACHMENT AT SLAB (N.T.S.): 8 anchor circles (2.8 pt outline, pen 0.24, grey fill) located from vector geometry in the plan view. Coordinates in the displayed (rotated) page space.

Names come from: no legend on this sheet, so NECA 100-2006 is what a name rests on. It is the baseline for what a symbol MEANS, never for matching shapes — proportions differ per firm. Confirming a name here is a correction, and corrections are what build the firm's file.

Scale is UNSET. Nothing on this sheet has been measured. The reader declined to infer a scale rather than guess one, so there is no raceway and no branch wire off this sheet — together the largest block of material on a job of this kind. Set it from the title block and measurement becomes available.
