Read from the text layer in 119 ms: 11,449 characters across 518 laid-out runs, tier 1. Marks below are TEXT labels at their own positions, not a geometry sweep — on a tier-1 set text tag counts beat a visual sweep, and a mark read off a label arrives named rather than as a shape nobody can identify. Scale read off the sheet as 1/4" = 1'-0" — 18 points per foot. This sheet carries MORE THAN ONE scale (1/4" = 1'-0", 1/8" = 1'-0"); the lowest callout on the page is taken as the main plan's and the rest are reported. A measurement taken under the wrong one is wrong by the ratio between them. No schedule was found on this sheet, so the whole plan area was swept.
Names come from: no legend on this sheet, so NECA 100-2006 is what a name rests on. It is the baseline for what a symbol MEANS, never for matching shapes — proportions differ per firm. Confirming a name here is a correction, and corrections are what build the firm's file.
Scale is 1/4" = 1'-0" — 18 points per foot. Read off the title block, so measurement off this sheet is available. A later correction flags any measurement taken under the old scale as stale rather than silently recomputing it.
18 pt/ft
