Specification sheet (16000 ELECTRICAL), lettering drawn as vector outlines. No plan and no drawn device symbols: every symbol-scan group is a text glyph. Nothing counted off this sheet; the spec clauses that change quantities (EMT everywhere, MC only for J-box-to-fixture whips, #10 on homeruns over 100 ft, dedicated neutrals) are recorded as coverage notes for the plan sheets.
Names come from: no legend on this sheet, so NECA 100-2006 is what a name rests on. It is the baseline for what a symbol MEANS, never for matching shapes — proportions differ per firm. Confirming a name here is a correction, and corrections are what build the firm's file.
Scale is UNSET. Nothing on this sheet has been measured. The reader declined to infer a scale rather than guess one, so there is no raceway and no branch wire off this sheet — together the largest block of material on a job of this kind. Set it from the title block and measurement becomes available.
