Title 24 NRCC-LTI-E indoor lighting compliance forms (pages 1-6 of 10). No plan and no drawn device symbols (symbol scan 0 groups, no scale); nothing counted off this sheet. Compliance fixture counts and control requirements recorded as coverage notes for reconciliation with E2.0.
Names come from: no legend on this sheet, so NECA 100-2006 is what a name rests on. It is the baseline for what a symbol MEANS, never for matching shapes — proportions differ per firm. Confirming a name here is a correction, and corrections are what build the firm's file.
Scale is UNSET. Nothing on this sheet has been measured. The reader declined to infer a scale rather than guess one, so there is no raceway and no branch wire off this sheet — together the largest block of material on a job of this kind. Set it from the title block and measurement becomes available.
